3 Installation

882 Compact IC plus – Cation

■■■■■■■■

11

Connect the separation column (see Chapter 3.15, page 37)

– Connect the inlet oft the separation column either with the

end of the column input capillary using a short pressures
screw (6.2744.070).
OR
Connect the inlet of the separation column with the guard
column (if used) (see leaflets to the separation column and
the guard column)

– Fasten the detector inlet capillary to the output of the sepa-

ration column using a short pressure screw (6.2744.070).

Hang separation column with chip in the column holder of the
instrument.

8 Conditioning the instrument

(see Chapter 4.2, page 40)

The instrument is now ready for measuring samples.

3.3

Installation diagram

The following installation diagram shows the schematics of the front of
the instrument after installation is complete. Many capillaries are already
installed at the time the instrument is delivered; these capillaries are not
numbered in the diagram. Numbered capillaries must be connected at the
time of installation.
