Metrohm 882 Compact IC plus – Cation - Manual (Page 32)

3.8 Eluent ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
24 ￭￭￭￭￭￭￭￭ 882 Compact IC plus – Cation
1
1
2
3
4
5
6 7 8 9
10
11
12
13
14
Figure 12 Eluent bottle – connected
2 Eluent aspiration tubing (6.1834.080)
For aspirating the eluent. Pre-installed. 2 Adsorber tube (6.1609.000)
3 Cotton 4 CO
2
adsorber
Adsorbs CO
2
from the air (e.g. Merck soda
lime with indicator, no. 6839.10).
5 Eluent 6 Aspiration filter (6.2821.090)
7 Filter holder
From accessories set (6.2744.210). 8 Clamping screw
From accessories set (6.2744.210).
9 Tubing weighting
From accessories set (6.2744.210). 10 Eluent bottle (6.1608.070)
11 Bottle attachment (6.1602.160) 12 SGJ clip (6.2023.020)
13 Tubing nipple 14 Threaded stopper
