￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 5 Handling and maintenance
882 Compact IC plus – Cation ￭￭￭￭￭￭￭￭ 53
1
3
4
2
Figure 27 Dismantling valve
1 Needle
For pushing the valve components out of
the valve housing. 2 valve
3 Recess
For collecting the valve components. 4 Holder
The components of the valve are collected in the recess of the
holder.
Note
The components of the valve are very small. In order not to lose
them, put the components into a dish.
￭ The inlet valve and the outlet valve consist of the same, just differ-
ently arranged components (see Figure 28, page 54).
