10.6 Remote interface
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
106 ￭￭￭￭￭￭￭￭
877 Titrino plus
A progress bar is displayed. If the key is released during this time,
then the instrument will not be switched off.
2 Switching on the instrument
￭ Keep the red [STOP] key pressed down for approx. 10 s.
The dialog for confirmation of the initialization is displayed for 8 s.
The initialization must be confirmed during this time.
3 Confirming the initialization
NOTE
If the request is not confirmed within 8 s, then the procedure will
be canceled.
￭ Press [BACK] twice.
Initialization is started. The process takes approximately 80 s. The
instrument will be automatically restarted after successful initializa-
tion.
10.6 Remote interface
10.6.1 Pin assignment of the remote interface
1
5
6
9
5
1
9
6
Figure 20 Pin assignment of remote socket and remote plug
The above figure of the pin assignment applies for all Metrohm instru-
ments with 9-pin D-Sub remote connector.
