the Elevator Stick up the Slide will move to the right and the craft will move Foward (away from you);
A : If you move the Aileron stick to the left the Slide will move left and the craft will move to the left, when
you move the Aileron stick to the Right the slide will move to the right and the craft will move to the right.
1. Set endpoints of all channels to default values (100%) and set all trims and sub-trims of sticks to 0 on your
transmitter first. Keep all curves’ settings as default since the end-point of transmitter sticks will be
recorded here.
2. Click the START button, and move all of the sticks throughout their
complete range several times.
3. After you do this, click the FINISH button when you have finished the
above procedures.
4. If the slides are moving opposite from your stick movements direction, click the reverse button
REV/NORM beside.
Notices:
1. All slides should become when all the sticks are in the middle positions. If slides cannot go back to
center points (become ), just click FINISH, then slides will be at center automatically. If still not, please
reboot MC, and do not apply TX command during the reboot.
2. CSC may not start motors If trims and sub-trims of sticks are not 0!
STEP3: Sticks Monitor
This step is optional. If it is necessary for you, please setup the channel on your R/C TX correctly, and then you can
monitor the X1 and X2 Channels on this page.
Tips:
 X1 Channel is for remote gain tuning or gimbal pitch control.
 X2 Channel is for remote gain tuning or Intelligent Orientation Control (IOC), or as S-Bus input.
Receive Type Receive Type
STEP4: Control Mode Switch
Whether you are using a 2 or 3 position switch on your transmitter will determine which you will use as the control
mode switch, Plug in the right channel of receiver (Gear, Aux 1 or aux 2) to the U port of MC. At each switch position,
use the end-point for fine tuning on your transmitter, Move the Switch to the corresponding Mode as indicated by
the slider of channel U to GPS (GPS Atti Mode), A (Atti. Mode), M (Manual Mode) to turn the corresponding area
blue respectively as showed in the figure.
