Decimator Design DMON-12S User Manual

Page 4

DMON‐12S Hardware Manual for Firmware Version 1.1

Press the < and > buttons to move left or right respectively through the 12 menus below and press the BACK
button to go back to the Main Menu when finished.
The current value for each Sub Menu is shown in the Parameter Window.

1. Control / HDMI Output Type (Parameter)
This is the current HDMI output type for output 1.
When the sub menu is highlighted, press ENTER to toggle through the following types:

1.) DVI RGB444

DVI‐D RGB 4:4:4

2.) HDMI RGB444 2C

HDMI RGB 4:4:4 with 2‐Channels of Audio

3.) HDMI YCbCr444 2C

HDMI YCbCr 4:4:4 with 2‐Channels of Audio

4.) HDMI YCbCr422 2C

HDMI YCbCr 4:2:2 with 2‐Channels of Audio

5.) HDMI RGB444 8C

HDMI RGB 4:4:4 with 8‐Channels of Audio

6.) HDMI YCbCr444 8C

HDMI YCbCr 4:4:4 with 8‐Channels of Audio

7.) HDMI YCbCr422 8C

HDMI YCbCr 4:2:2 with 8‐Channels of Audio

2. Control / Output Select (Parameter)
This is the current source for the HDMI and SDI outputs.
When the sub menu is highlighted, press the ENTER button to enter this sub‐menu.
Press the < and > buttons to move left or right through the following sources:

1.) Multi‐View
2.) Window 1
3.) Window 2
4.) Window 3
5.) Window 4
6.) Window 5
7.) Window 6
8.) Window 7
9.) Window 8
10.) Window 9
11.) Window 10
12.) Window 11
13.) Window 12

3. Control / MV Output Format (Parameter)
This is the current output format for the Multi‐Viewer.
When the sub menu is highlighted, press the ENTER button to enter this sub‐menu.
Press the < and > buttons to move left or right through the 26 video formats listed below and the BACK button
to leave this SUB‐MENU.
1. SD 720x487i59.94

11. HD 1920x1080p30

21. HD 1280x720p25

2. SD 720x576i50

12. HD 1920x1080p29.97

22. HD 1280x720p24

3. HD 1920x1080i60

13. HD 1920x1080p25

23. HD 1280x720p23.98

4. HD 1920x1080i59.94

14. HD 1920x1080p24

24. 3G 1920x1080p60

5. HD 1920x1080i50

15. HD 1920x1080p23.98

25. 3G 1920x1080p59.94

6. HD 1920x1080psf24

16. HD 1280x720p30

26. 3G 1920x1080p50

7. HD 1920x1080psf23.98

17. HD 1280x720p29.97

4. Control / MV Windows (Parameter)
This is the current number of windows shown on the multi‐view output.
When the sub menu is highlighted, press the ENTER button to enter this sub‐menu.
Press the < and > buttons to move left or right through the number of windows displayed from 1 to 12.
Default Windows displayed is 12 windows.
