4. Graticules / S.Action All Off (Action)
Pressing ENTER when this submenu is selected will turn all Safe Action Graticules overlays off.
5. Graticules / S.Title All Off (Action)
Pressing ENTER when this submenu is selected will turn all Safe Title Graticules overlays off.
6. Graticules / C.Cross All Off (Action)
Pressing ENTER when this submenu is selected will turn all Centre Cross overlays off.
7. Graticules / All Anamorphic (Action)
Pressing ENTER when this submenu is selected will set all Safe Action and Safe Tile Graticules to anamorphic.
8. Graticules / All 16:9 LB (Action)
Pressing ENTER when this submenu is selected will set all Safe Action and Safe Tile Graticules to 16:9 Letter
Box on a 4:3 Raster. For use with 16:9 and HD/SD inputs being displayed on a 4:3 SD output.
9. Graticules / All 4:3 PB (Action)
Pressing ENTER when this submenu is selected will set all Safe Action and Safe Tile Graticules to 4:3 Letter Box
on a 16:9 Raster. For use with 4:3 SD inputs being displayed on a 16:9 HD/SD output.
GPI: (Has SUB‐MENUs)
GPI
GPI Mode
00
Main Menu <==
Sub Menu
Parameter Window
When highlighted in the Main Menu, press the ENTER button to enter this sub‐menu.
When the sub menu is highlighted, press ENTER to toggle through the Modes and press the BACK button to go
back to the Main Menu when finished.
The current value for each Sub Menu is shown in the Parameter Window.
GPI Mode = 00:
PIN 1 = Ground PIN 14 = Window 11 Tally Red PIN 27 = Window 12 Tally Green
PIN 2 = RS485+ PIN 15 = Window 1 Tally Green PIN 28 = Window 2 Tally Red
PIN 3 = Window 1 Tally Green PIN 16 = Window 3 Tally Green PIN 29 = Window 4 Tally Red
PIN 4 = Window 3 Tally Green PIN 17 = Window 5 Tally Green PIN 30 = Window 6 Tally Red
PIN 5 = Window 5 Tally Green PIN 18 = Multi‐View Select PIN 31 = Window 8 Tally Red
PIN 6 = Window 7 Tally Green PIN 19 = Ground PIN 32 = Window 10 Tally Red
PIN 7 = Window 9 Tally Green PIN 20 = Ground PIN 33 = Window 12 Tally Red
PIN 8 = Window 11 Tally Green PIN 21 = RS485‐ PIN 34 = Window 2 Tally Green
PIN 9 = Window 1 Tally Red PIN 22 = Window 2 Tally Green PIN 35 = Window 4 Tally Green
PIN 10 = Window 3 Tally Red PIN 23 = Window 4 Tally Green PIN 36 = Window 6 Tally Green
PIN 11 = Window 5 Tally Red PIN 24 = Window 6 Tally Green PIN 37 = Output Select Toggle
PIN 12 = Window 7 Tally Red PIN 25 = Window 8 Tally Green
PIN 13 = Window 9 Tally Red PIN 26 = Window 10 Tally Green
