2 Getting Started
1.2 Printer Specifications
Mechanical
Width 8.8" (22.35 cm)
Depth 10.1" (25.65 cm)
Height 6.2" (15.75 cm)
Weight 7 lbs. (15.4 kg)
Operating Temperature 40
°
F to 100
°
F (4
°
C to 38
°
C)
Printer Specifications
Print Type Thermal Transfer
Print Speed 1, 1.5, and 2" per second
Resolution 203 dpi (8 dots/mm)
Tear Bar Tear up
DRAM Memory 512 kb
EPROM Memory 512 kb
Media/Ribbon
Media Types Roll-Fed, Die-Cut, Continuous, Fan-Fold
Max. Media Width 4.65" (118 mm)
Max. Print Width 4.1" (104 mm)
Min. Print Width 1" (25 mm)
Max. Print Length 12" (305 mm) with standard RAM
Min. Print Length .375" (.95 cm)
.5" (1.27 cm) w/ Present Sensor
Media Thickness .0025" - .01" (.0635 mm - .254 mm)
Ribbon Matched to Media; approx. 4330"(110m)
long
1.5" O.D. on .5" core
