About your printer, About your printer -2 – Brother HL 1270N User Manual
Page 10
1-2
About your printer
Fig. 1-2 Front View
10/100BASE TX
L F A
TEST
Fig. 1-3 Network Board
Fig. 1-4 Rear View
Face down output tray
Tray extension flap
Manual feed slot
Control panel
Paper cassette
Front cover
Manual feed paper guides
Power switch
AC power inlet
Parallel Interface connector
USB (Universal Serial Interface Bus)
connector
Rear cover
Modular jack for lower tray unit
10/100Base TX port
LED
Test button
