Installing the Panel
1. Place panel in an empty slot on the rack and attach with mounting
screws (optional).
2. Connect the panel to a power supply.
3. Attach a TPM to one of the available channels on the back of the panel.
4. Label what TPM is attached to which channel in the switch nota-
tion area on the front of the panel.
Note:
User should note each unit’s full scale power and
location in the notation area. Use a water soluble marker to
avoid permanent entries.
5. Repeat steps 3 and 4 for other TPM’s, if necessary.
6. Turn the panel on.
Note:
All TPMs are powered, but only one TPM output is
displayed at a time.
7. Select the desired TPM to be measured by using the channel selector.
Note:
The pots adjust the meter independently of TPM
calibration. The appropriate meter scale (1/2.5/5) must be
used with each TPM.
FWD/RFL
Meter
Provides visual indication of measured power for
selected TPM.
Meter Adj
Pot
Provides full scale meter calibration.
Channel
Selector
Selects either one of four (3140A4) or one of eight
(3140A8) connected TPM’s.
Power
Button
Applies DC input power to panel meter.
Zero
Calibrate
Switch
Grounds pin 9 to Zero calibrate the selected TPM.
DB9
Connection
Interface connection to TPM’s. Provides power and
Zero adjust to connected TPM’s. Receives TPM
output to drive meters.
