21
Replacement Parts List
Coupling Kits
Qty. Description Part Number
1 BR1, Rectifier, full wave silicone bridge 5-1661
1 LS1, Buzzer, alarm 5-1714
2 F1 - F2, Fuse .125A at 250 Vac 5A2257-7
1 LS1, Fuse holder, alarm 5A2295-1
2 K1, Power relay, 3pdt 5A2116-1
1 M2, Meter, triple scale, incident power
- Model 3126, 100uA 15/30/60kW scale
- Model 3127, 100uA 5/10/25kW scale
- Model 3128, 30uA 25/50/100W scale
2150-259
2150-230
2150-256
1 M1, Meter, triple scale, reflected power
Model 3126, 100uA 1.5/3.0/6.0kW scale
Model 3127, 100uA 1.0/2.5/5.0kW scale
Model 3128, 30uA 25/50/100W scale
2150-257
2150-259
2150-258
1 S1, Alarm, enable/disable switch 5-1899-42N
1 S2, Alarm level adjust switch 5-1899-42N
1 S3, Alarm reset switch 5A2292-21-CN
1 S4, Mode selector switch 5-1899-42N
1 T1, Power transformer 5A2309-8
1 AC power input receptacle 5A2297
1 J4, Remote terminal plug connector (4 contacts) 5A2075-4
1 J5, Interlock terminal plug connector (6
contacts) 5A2075-6
2 J1 - J2, BNC connectors 5A2319-1
Line Type Impedance Kit Part Number
7 / 8 “ EIA flanged 50 Ω 4240-220
1&” EIA flanged 50 Ω 4712-020
3@“ EIA flanged 50 Ω 4600-020
3@” EIA flanged 50 Ω 5-726
6@“ EIA flanged 50 Ω 5-1322
6@” EIA flanged 50 Ω 4902-020
