Coronis Fusion 10MP 41
T
O MANUALLY SELECT A GRAYSCALE CONVERSION MODE
:
1 Bring up the OSD main menu.
2 Navigate to the Configuration > Image Sources > (Left/Right)
Image Source menu.
3 Enter the Grayscale Conversion submenu.
4 Select one of the available color conversion modes and confirm.
Use Green Channel This mode is intended for grayscale
displays where gray is sent over the green
channel.
Use Blue Channel This mode is intended for grayscale
displays where gray is sent over the blue
channel.
Use All Channels This mode is intended for grayscale
displays where gray is sent over the red,
green and blue channel. This done by
means of a standard conversion
mechanism where 30% red, 59% green
and 11% blue are used to generate gray.
