38 Coronis Fusion 10MP
Video input signals
A
BOUT VIDEO INPUT SIGNALS
The available input signals for your display are:
T
O MANUALLY SELECT A VIDEO INPUT SIGNAL
:
1 Bring up the OSD main menu.
2 Navigate to the Configuration > Image Sources > (Left/Right)
Image Source menu.
3 Enter the Input Signal submenu.
4 Select one of the available input signals and confirm.
Your C ORONIS F USION 10MP display automatically detects the
connected video input signals. Manually selecting image
source video input signals is possible, but then your display’s
image source selection mode should be set to allow this.
Please refer to “Image source selection modes” on page 36
to do this.
DisplayPort 1 This input corresponds to the DisplayPort 1
connector as shown in the “Parts, controls
and connectors” section.
DVI 1 This input corresponds to the DVI 1
connector as shown in the “Parts, controls
and connectors” section.
DisplayPort 2 This input corresponds to the DisplayPort 2
connector as shown in the “Parts, controls
and connectors” section.
DVI 2 This input corresponds to the DVI 2
connector as shown in the “Parts, controls
and connectors” section.
