36 Coronis Fusion 10MP
Image scaling
A
BOUT IMAGE SCALING
Enabling image scaling will multiply each individual pixel to one or more
adjacent pixels so that the size of the displayed image will be a multiple
of the original image source video input signal.
T
O ENABLE
/
DISABLE IMAGE SCALING
:
1 Bring up the OSD main menu.
2 Navigate to the Configuration > Image Sources menu.
3 Enter the Scaling submenu.
4 Select Enabled/Disabled as desired and confirm.
Image source selection modes
A
BOUT IMAGE SOURCE SELECTION MODES
Your C
ORONIS
F
USION
10MP display automatically detects the number of
video input signals connected, attaches them to the correct display side
and applies the correct video settings to it (resolution, video encoding
mode, refresh rate,...). However, it may be needed to manually select
the video input signal(s) to be displayed on a certain display side or to
Image scaling is only possible when the resolution of your
display’s video input signal is less than or equal to half the
maximum resolution of the display.
