7
The following information is provided regarding the
ABS ECU on the status screen:
ECU Information
Information
Displayed
Explanation of information
Model
ABS ECU model reference such as
EC-60
™ , TABS-6 , EC-17, EC-30 ™ /
EC-30 ™ T, U12, U16, 2X, A-18
Part number Bendix ABS ECU part number
Serial number Bendix ABS ECU serial number
Software
number Bendix ABS ECU software release
number
ABS
confi guration Number of sensors and modulators the
ECU is currently confi gured for
Traction
Control
Displays mode(s) of ATC ECU is
currently confi gured as either engine
or brake, no control if ABS ECU is not
confi gured for ATC but supports it. N/A
if ECU does not support ATC
PLC support
Will only indicate when a tractor ECU
can support receiving DTC information
over PLC with a Yes or No
Engine hours/
odometer
Will display engine hours if it is a
tractor, displays odometer mileage if a
trailer or displays N/A if information is
not available
ADL Program #
Will display the ADL Program the ABS
ECU currently has programmed in it.
Stability
Control Will display only if the ABS ECU
supports any stability control
HSA
Will display if EC-60 ™ ECU supports
Hill Start Aid
Status Information
Information
Displayed Explanation of information
Input Voltage The battery voltage read at the power
input connections to the ABS ECU
Active DTCs The number of active diagnostic trouble
codes read from the ABS ECU.
Event History The number of diagnostic trouble codes
recorded in the ABS ECU history. Will
not show if ECU does not support this
function. This information is read once
when screen is opened.
Lamps
Lamp If lamp is illuminated (highlighted) this indicates
diagnostic trouble code(s) within the ABS and/or
ATC system
ABS ABS indicator lamp when illuminated indicates
active diagnostic trouble code(s) with a
component in the ABS system. User may double
click on illuminated lamp to go to DTC screen
ATC
or
ESP ATC indicator lamp when illuminated indicates
active diagnostic trouble code with a component
in the ATC system. User may double click on
illuminated lamp to go to DTC screen.
NOTE: Will display ESP if the ABS ECU supports
the stability control
TABS Trailer in cab ABS indicator lamp indicates current
status of trailer ABS indicator lamp in the cab of
the tractor. The tractor ABS ECU must support
PLC functionality with a PLC complaint trailer in
order for the lamp to illuminate
Control Buttons
DTCs Will launch diagnostic trouble code
screen
Wheels Will launch wheel speed screen
Confi g Will launch confi guration screen
Report Provides a report of the status
information which can be e-mailed,
faxed, saved
Help Will launch the help for status screen
Close Will close the status screen
