TP10476-1 PAGE 20
2. Run Mode Functions
When the folder is started with the RUN/MAINT jumper in the RUN position, the system is enabled for
the user to make machine setups and to fold paper. The counter will start up in production mode, the
normal operating mode of the counter. In this mode, various job parameters can be displayed on the large
display (1), and the small display (2) shows the gap length. The suction length display (3) is active in this mode
and shows the suction length as a percentage of sheet length.
The DCT500 mode select keys perform the same function in all modes, except Counter Setup. This
allows a user to quickly switch between the operating modes on the counter. Select Make Ready is not a
mode unto itself, but rather is a modifier to all modes.
2.1 Machine Setup and Diagnostic Mode
Pushing this key puts the controller in machine setup mode.
Machine setup mode provides a method to view and optionally change operating parameters for the
controller. The decimal points in the large display (1) will move from side to side to indicate that a pa-
rameter may be changed. In this mode, the small display gives the selected parameter number, while the
large display (1) shows a parameter value. The suction length display (3) is disabled.
Parameter Selection
The plus (25) and minus (24) keys are used to move through the list of available parameters.
Selected Parameter Adjustment
If the large display (1) decimal points are moving, the set of minus and plus buttons will move through
the set of values for the selected parameter, see table 3 and 4.
2.1.1 Machine Setup Parameters
Table 1. DCT 500 Machine Setup Parameter List
# Function Type Variable Displayed
P00 Input Counter Setup Variables adjustable 1-24 - Std setting 1
P01 Output Counter Setup Variables adjustable 1 to Input Factor SV
Standard setting 1
P02 Tremat Setup Variables adjustable Standard: none 0
Tremat available 1
P03 Knife Setup Variables adjustable Standard : none 0
Knife available 1
P04 Ergonomic pile Setup Variables adjustable Standard: none 0
Ergo. available 1
P05 Kicker Setup Variables adjustable Standard : none 0
Kicker available 1
+
+ +
