PC 90 MANUAL

VERSION 1.0

5

AUTOCUE 2001

Attach all relevant cables.

1. Power input.

2. Power output for monitor

3. Data input

4. Local control socket

5. Data output.

Glass Holder

To install the glass into the
holder first loosen the clamp
screw so that the jaws of the
clamp are open. Insert the
glass and secure in the clamp
by retightening the clamp
screw. The angel of the glass
is adjustable and must be set at
45 degrees to the face of the
monitor. Please insure that the
blue dot on the face of the
glass is facing the presenter.

Glass Holder

Clamp Screw

1.

2.

3

4.

5.

Cable Set-up

Glass
