Rockwell Automation MPP Processor Moduile User Manual
Page 21

MPP October 2005 – Issue 6
21
Triguard SC300E MPP Processor Module
The locations of the links are shown in general view showing link locations.
Table 3-1. Module link settings
Fit Link
Across Pins
For Condition
Factory default
LK1
1 & 2
Data error monitoring
Yes
LK1
2 & 3
8MHz clock
No
LK2
Fit link
RTS-CTS loopback
Yes
LK3
1 & 2
5ms real time clock
No
LK3
2 & 3
10ms real time clock
Yes
LK4
1 & 2 and 3 & 4
Loopback operation
No (test use only)
LK5
1 & 2
4Mbit RAM devices
No
LK5
2 & 3
1Mbit Ram devices
Yes
LK6
1 & 2 and 3 & 4
Loopback operation
No (test use only)
LK7
Fit link
Write operations to flash memory
No
LK8
1 & 2
1Mbit or 2Mbit EPROMs
Yes
LK8
3 & 4
<1Mbit EPROMs
No
LK9
1 & 2 and 3 & 4
Loopback operation
No (test use only)
LK10
Fit link
Slow EPROM (
<
70ns)
Yes
LK11
Fit all links
Loopback operation
No (test use only)
LK12
Fit link
CPU self test
Yes
LK13
Fit link
Supervisory watchdog
No
LK14
Position 1
Logic 5V
Not applicable on
Modules at Rev 04
and above
LK14
Position 2
Battery backup enabled
No
LK14
Position 3
Battery backup disabled
Yes
