Page 2
Anorad, Allen-Bradley, Rockwell Software, and Rockwell Automation are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
Rockwell Otomasyon Ticaret A.Ş., Kar Plaza İş Merkezi E Blok Kat:6 34752 İçerenköy, İstanbul, Tel: +90 (216) 5698400
Publication LZ-IN001B-EN-P - August 2011
814067
Supersedes Publication LZ-IN001A-EN-P - July 2009
Copyright © 2011 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
3.
Attach the manifold to the coil mounting bar as shown by securing to the
tapped holes with M4 SHCS.
Torque to 3.4 Nm (30 lbin) using a 3 mm hex key.
4.
Install the barb fittings to the cable end of the coil.
Torque to 3.4 Nm (30 lbin) using an 8 mm wrench or nut driver.
Additional Resource
This document contain additional information concerning related Anorad
products.
You can view or download publications at
http://www.rockwellautomation.com/literature/
. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or
Rockwell Automation sales representative.
Resource
Description
LZ-Series Linear Motors User Manual, publication
LZ-UM001
.
Provides details about LZ-Series linear motors.
