Rockwell Automation T8461 Trusted TMR 24 48Vdc Digital Output Module - Manual (Page 19)

Trusted
TM
Module T8461
Issue 13 Apr 10 PD-T8461 19
OEM Parameter Description Notes
TICS_CHASSIS The number of the
Trusted TM Chassis
where the Primary I/O
module is installed
The Trusted TM Controller Chassis is 1, and Trusted TM
Expander Chassis are 2 to 15
TICS_SLOT The slot number in the
chassis where the
Primary I/O module is
installed The I/O module slots in the Trusted TM Controller
chassis are numbered from 1 to 8. The I/O Module
slots in the Trusted
TM Expander Chassis are
numbered from 1 to 12
Table 4 OEM Parameters
3.2.1. Rack 1: DO
This board provides the connection to the logical output control signal for each of the field outputs.
Channel Description
1 Field output channel 1 logical state
2 Field output channel 2 logical state
40 Field output channel 40 logical state
Table 5 Rack 1: DO descriptions
The user application should set the output control signal to true (logic ‘1’) to turn ON or energise an
output, and false (logic ‘0’) to turn OFF or de-energise an output.
3.2.2. Rack 2: STATE
This board provides the majority voted numerical output state. This indicates the operational status of
the output channel and associated field connection.
Channel Description
1 Field output channel 1 state
2 Field output channel 2 state
40 Field output channel 40 state
Table 6 Rack 2: STATE bit descriptions
