Page 8: Expander interface adaptor t8312
Trusted
TM
Expander Interface Adaptor T8312
Issue 10 Jun 08
PD-T8312
8
1.1. Chassis Connector (SK1)
SK1 is a double, 96-way DIN41612, C-type connector.
CONNECTOR SK1 PINOUT
Pin
A
B
C
1
RXC7-
RXC6-
RXC5-
2
RXC7+
RXC6+
RXC5+
3
RXC4-
RXC3-
RXC2-
4
RXC4+
RXC3+
RXC2+
5
RXC1-
LB_A_ACTN/STB_1
TXC7-
6
RXC1+
LB_A_ACTN/STB_2
TXC7+
7
TXC6-
TXC5-
TXC4-
8
TXC6+
TXC5+
TXC4+
9
TXC3-
TXC2-
TXC1-
10
TXC3+
TXC2+
TXC1+
11
GND
GND
GND
12
RXB7-
RXB6-
RXB5-
13
RXB7+
RXB6+
RXB5+
14
RXB4-
RXB3-
RXB2-
15
RXB4+
RXB3+
RXB2+
16
RXB1-
LB_B_ACTN/STB_1
TXB7-
17
RXB1+
LB_B_ACTN/STB_2
TXB7+
18
TXB6-
TXB5-
TXB4-
19
TXB6+
TXB5+
TXB4+
20
TXB3-
TXB2-
TXB1-
21
TXB3+
TXB2+
TXB1+
22
GND
GND
GND
23
RXA7-
RXA6-
RXA5-
24
RXA7+
RXA6+
RXA5+
25
RXA4-
RXA3-
RXA2-
26
RXA4+
RXA3+
RXA2+
27
RXA1-
LB_C_ACTN/STB_1
TXA7-
28
RXA1+
LB_C_ACTN/STB_2
TXA7+
29
TXA6-
TXA5-
TXA4-
30
TXA6+
TXA5+
TXA4+
31
TXA3-
TXA2-
TXA1-
32
TXA3+
TXA2+
TXA1+
Table 2 Chassis Connector (SK1) Pinout
