Installation
3-3
Step 6. Disconnect the METER PORTS plug connector from the module faceplate.
Use 14-22 AWG wire to connect the analog devices to terminals 1-4 of the
plug connector. Connect all of the COMMON leads from the analog devices
and run a single lead to terminal 5 (COM) on the plug connector. Re-connect
the plug connector to the module faceplate. Figure 3.3 illustrates the terminal
connections.
Figure 3.1 – Fiber-Optic Cable Connections
UDC
(XMT)
UDC
(RCV)
PMI
(RCV)
PMI
(XMT)
(BLUE)
(BLUE)
(ORG.)
(ORG.)
FIBER-OPTIC CABLE
FIBER-OPTIC
WIRE
P2
P3
XMT
RCV
C
O
M
M
L
I
N
K
PMI
UNIVERSAL
57652
DRIVE
CONTROLLER EM
CARD OK
OS OK
COMM A OK
DRV A FLT
COMM B OK
DRV B FLT
TEST
SWITCHES
1
2
3
N.O.
METER
PORTS
1
2
3
COM
4
COMM A
RCV
XMT
COMM B
RCV
XMT
