TAI16AEA October 2005 – Issue 6 3
Triguard SC300E TAI16AEA 16-Channel A/I Termination Module
Model TAI16AEA
Transient suppression A transient suppressor device between each field
return line and a common 0V bus clamps the field
return line voltage (with respect to 0V common) as
follows:
+37Vdc to +43Vdc @ 1mA (maximum for continuous
overload)
+70Vdc @ 69A maximum peak pulse current
for 8ms to 20ms
Safety ground terminal TS1 M3 threaded bush provision for a ring terminal. Allows
the common 0V supply bus to be grounded via a 10k
ohm resistor. Prevents the channels from floating if the
card is disconnected from the chassis.
Signal ground terminal TS2 M3 threaded bush provision for a ring terminal. Allows
J1 pin1a (field circuit) to be grounded.
Overall size (mm)
Overall size (inches)
162L x 111W x 107H
6.4L x 4.9W x 4.2H
Weight 0.20kg
ENVIRONMENTAL SPECIFICATIONS
The maximum ambient temperature measured at the hottest point within the Triguard system
shall not be greater than 60 degrees centigrade.
Temperature operating: +5°C to +60°C
Temperature storage: -25°C to +70°C
Humidity 5% to 95% non-condensing at ambient <40°C
EMC/RFI Immunity Tested and certified to IEC 1131-Part 2 1994
Vibration/Shock Tested and certified to IEC 1131-Part 2 1994
Certification:
General Certification: Ref. SC300E Product Guide (ref 008-5209)
TRANSPORT AND HANDLING
The TAI16AEA must be transported and stored in its original packing material which should be
retained for this purpose.
