Select – Rockwell Automation DeviceNet System Quick Reference User Manual
Page 4
DeviceNet System Quick Reference
DNET-QR001A-EN-E – March 2009
4
Select
Use this table to select the appropriate media for your system. For other media choices, refer to
Chapter 6 in the On-Machine Connectivity Catalog, publication
M116-CA001
.
Description
Cat. No.
DeviceNet handheld configuration terminal
193-DNCT
IP20 flat media
1485-P1W100
Trunk-line connector, IDC
1485P-K1TG4
Drop-line connector, IDC
1485P-K1DL4
Terminating resistor, IDC
1485P-K1TR4
Terminal block, IDC
1485P-K1TLR4
Flat-to-thin round cable converter, IDC
1485P-K1GK4
5-pin open style connector, IDC
1485P-K1G4-Y5
Manual crimp tool
1485A-KCRIMP
ControlLogix DeviceNet scanner module
1756-DNB
CompactLogix DeviceNet scanner module
1769-SDN
4-in/2-out block I/O 120V AC relay DSA
100-DNY41R
4-in/2-out block I/O 24V DC relay DSA
100-DNY42R
AC/DC DIN-rail mount power supply, DeviceNet 4 A
1606-XLDNET4
E1 DeviceNet module for 193 E1 plus overload relay
193-EDN
PowerFlex DeviceNet communication interface
22-COMM-D
Thin round cable, 50 m (164 ft) roll
1485-P1C50
Terminating resistor
1485A-C2
