Trusted
TM
Module T8472
Issue 13 Sep 11
PD-T8472
15
OEM Parameter Description
Notes
TICS_CHASSIS The number of the Chassis
where the Primary I/O
module is installed
The Controller Chassis is 1, and Expander
Chassis are 2 to 15
TICS_SLOT
The slot number in the
chassis where the Primary
I/O module is installed
The I/O module slots in the Controller chassis are
numbered from 1 to 8. The I/O Module slots in the
Expander Chassis are numbered from 1 to 12
Table 4 OEM Parameters
3.2.1. Rack 1: DO
This board provides the connection to the logical output control signal for each of the field outputs.
Channel
Description
1
Field output channel 1 logical state
2
Field output channel 2 logical state
16
Field output channel 16 logical state
Table 5 Rack 1: DO descriptions
The user application should set the output control signal to true (logic ‘1’) to turn ON or energise an
output, and false (logic ‘0’) to turn OFF or de-energise an output.
3.2.2. Rack 2: STATE
This board provides the majority voted numerical output state. This indicates the operational status of
the output channel and associated field connection.
Channel
Description
1
Field output channel 1 state
2
Field output channel 2 state
16
Field output channel 16 state
Table 6 Rack 2: STATE descriptions
