2.2. Field Power Connection
May be connected at the T8871 Field Termination Adapter. However Field Power may be connected
any where along the cable by pulling the Field Power Cables (Grey & White) out of the outer sheath
and connecting onto suitable junction boxes.
2.2.1. Cable Impedance
Custom length multi-core FTA cables are 0.5mm
2
with a resistance of 40M/km. eg a 50m cable will
have 4M loop impedance at 0.5A, this equates to a 2Vdc volt drop.
2.3. Termination
Unused channels should be commanded OFF and may be fitted with a 33k 2W resistor to prevent no-
load detection.
2.4. Module Pinout Connections
Field Connections are made to the Modules DIN41612 type D Field Connector:
Table 2 Field Connector Pin-Out
Pin No.
Row a
Row c
2
(SMART_SLOT_A)
(SMART_SLOT_B)
4
(SMART_SLOT_C)
spare
6
V_RET_CH9_16
V_RET_CH1_8
8
V_FIELD_CH9_16
V_FIELD_CH1_8
10
V_FIELD_CH9_16
V_FIELD_CH1_8
12
V_FIELD_CH9_16
V_FIELD_CH1_8
14
V_FIELD_CH9_16
V_FIELD_CH1_8
16
V_FIELD_CH9_16
V_FIELD_CH1_8
18
LOAD_CH9
LOAD_CH1
20
LOAD_CH10
LOAD_CH2
22
LOAD_CH11
LOAD_CH3
24
LOAD_CH12
LOAD_CH4
26
LOAD_CH13
LOAD_CH5
28
LOAD_CH14
LOAD_CH6
30
LOAD_CH15
LOAD_CH7
32
LOAD_CH16
LOAD_CH8
