Assembly pinout connections, Pwr tb connections – Rockwell Automation T8850 Trusted Analogue or Digital Output FTA User Manual
Page 9
Trusted
TM
Analogue or Digital Output FTA T8850
Issue 10 Apr 12
PD-T8850
9
4. Assembly Pinout Connections
4.1. PWR TB Connections
Pin
Service
1
V_FIELD_GRP5
2
V_FIELD_RTN_GRP5
3
V_FIELD_GRP4
4
V_FIELD_RTN_GRP4
5
V_FIELD_GRP3
6
V_FIELD_RTN_GRP3
7
V_FIELD_GRP2
8
V_FIELD_RTN_GRP2
9
V_FIELD_GRP1
10
V_FIELD_RTN_GRP1
Table 1 PWR TB Connections
