Analogue or Digital Output FTA T8850
Issue 10 Apr 12 PD-T8850 11
4.3. SK1
C B A
1 Smart Slot Link C Smart Slot Link B Smart Slot Link A
2
3 Chan 5 V_FIELD_GRP1 Chan 1
4 Chan 6 V_FIELD_GRP1 Chan 2
5 V_FIELD_RTN_GRP1 V_FIELD_GRP1 V_FIELD_RTN_GRP1
6 Chan 7 V_FIELD_GRP1 Chan 3
7 Chan 8 V_FIELD_GRP1 Chan 4
8
9 Chan 13 V_FIELD_GRP2 Chan 9
10 Chan 14 V_FIELD_GRP2 Chan 10
11 V_FIELD_RTN_GRP2 V_FIELD_GRP2 V_FIELD_RTN_GRP2
12 Chan 15 V_FIELD_GRP2 Chan 11
13 Chan 16 V_FIELD_GRP2 Chan 12
14
15 Chan 21 V_FIELD_GRP3 Chan 17
16 Chan 22 V_FIELD_GRP3 Chan 18
17 V_FIELD_RTN_GRP3 V_FIELD_GRP3 V_FIELD_RTN_GRP3
18 Chan 23 V_FIELD_GRP3 Chan 19
19 Chan 24 V_FIELD_GRP3 Chan 20
20
21 Chan 29 V_FIELD_GRP4 Chan 25
22 Chan 30 V_FIELD_GRP4 Chan 26
23 V_FIELD_RTN_GRP4 V_FIELD_GRP4 V_FIELD_RTN_GRP4
24 Chan 31 V_FIELD_GRP4 Chan 27
25 Chan 32 V_FIELD_GRP4 Chan 28
26
27 Chan 37 V_FIELD_GRP5 Chan 33
28 Chan 38 V_FIELD_GRP5 Chan 34
29 V_FIELD_RTN_GRP5 V_FIELD_GRP5 V_FIELD_RTN_GRP5
30 Chan 39 V_FIELD_GRP5 Chan 35
31 Chan 40 V_FIELD_GRP5 Chan 36
32
Table 3 SK1 Connections
