Rockwell Automation 20D PowerFlex 700H/700S AC Drives Frames 13 and 14 Main Fan Capacitor Rplcmnt. Kit User Manual
Page 9
Rockwell Automation Publication PFLEX-IN027A-EN-P - July 2011
9
PowerFlex 700H and 700S AC Drives Frames 13 and 14 Main Fan Capacitor Replacement Kit
9. Secure the fan capacitor bracket to the drive chassis using the M8 x 12 mm
hexagonal socket screw and spring washer provided as shown below.
Tightening torque is 20 N
•
m (178 lb
•
in).
Fan capacitor bracket
Fan inverter
circuit board
Washer and screw
Side view of fan
capacitor bracket
Front of drive
Front view of drive and
fan capacitor bracket
