User manual MIVD 1218 8
(3) Control wheel for navigating through the on-screen display (OSD)
menus and changing values in the menus
RS232 DVI VIDEO CS/HS VS
(SERVICE ONLY)
Power
(4) Control (rs-232) connector
Note: To comply to EMC regulations, the used RS-232 cable must
be provided with a ferrite core.
(5) DVI (video and data) input
(6) Composite video input
(7) Composite / Horizontal sync input
(8) Vertical sync input
(9) AC power input
3
Input panel
at the rear
4 5 6 7 8 9
Connector not used
