To connect analog video & sync signals:
Connect the video & sync output of the signal source to the video
and sync inputs (6), (7) and (8) of the display.
The inputs accept the following signals:
• Video with separate horizontal and vertical sync.
- The connection consists of 3 cables.
- Connect the video signal to the connector Video (6).
- Connect the horizontal sync signal to connector HS/CS (7).
- Connect the vertical sync signal to the connector VS (8).
- Make sure the signal connected to the HS/CS connector does
not contain Composite sync.
• Video with external composite sync.
- The connection consists of 2 cables.
- Connect the video signal to the connector Video (6).
- Connect the composite sync signal to connector HS/CS (7).
- Make sure no signal is connected to the VS connector.
• Video with internal composite sync (sync on video).
- The connection consists of 1 cable.
- Connect the video (with sync) signal to connector Video (6).
Notes:
• The video inputs cannot be connected in loop-through (daisy-
chain).
• The required video amplitude: 700 mV ± 3 dB.
• The required sync. amplitude: 500 mV.
To connect the power:
1 Plug one end of the power cord into the rear of the display
(connector (9)).
2 Plug the other end into a grounded AC power outlet.
3 The display automatically adapts to the voltage. The voltage
range is: 90-264 VAC.
After fixing the cables, put the connector compartment cover back in
place. Pay attention that the signal cables are positioned under the
bulge in the cover.
