User manual MIVD 1218 30
6. Technical specifications
GEOMETRY
• Screen size: 46 cm
(18.1")
• Display area: 359 mm x
287 mm (14.1" x 11.3")
• Aspect ratio: 5:4
VISUAL PERFORMANCE
General
• Pixel arrangement: sub-
pixel vertical stripes
• Pixel pitch: 0.2805 mm x
0.2805 mm (0.011" x
0.011")
• Panel contrast ratio:
550:1 (typical)
• Panel viewing angle: +/-
85° (at CR = 10:1)
Panel
• Thin film transistor active
matrix grayscale LCD
• PVA technology
• Amorphous silicon TFT
• Backlight: 6 cold
cathode fluorescent
lamps
Luminance
• Calibrated: 500 cd/m2
(145.9 fL)
Resolution
• Up to 1280 x 1024 (1.3
MegaPixel)
INPUTS
DVI
• Complies to DVI Rev.
1.0 spec
Video
• Connector type: BNC
• Inputs provided:
composite video
• Video input voltage:
nominal 0.7Vpp
• Termination: 75 Ohm
Sync
• Connector type: BNC
• Inputs provided: HS/CS
and VS
• Sync input voltage:
nominal 2Vpp
• Termination: 75 Ohm
SCANNING SYSTEM
• Horizontal Frequency:
15 - 95 kHz
• Vertical Frequency: 50 -
140 Hz
• Interlaced / non-
interlaced signals
• Interlaced: Fuzzy-logic-
based de-interlacing
• Multi-sync
• 14 programmable scan
modes
