10 XM ControlNet Adapter
Publication ICM-IN001B-EN-P - March 2013
2. Hook the lip on the rear of the adapter onto the top of the DIN rail,
and rotate the adapter module onto the rail.
3. Press the adapter module down onto the DIN rail until flush. Locking
tab C will snap into position and lock the adapter module to the DIN
rail.
4. If the adapter module does not lock in place, use a screwdriver or
similar device to move the locking tab down while pressing the
adapter module flush onto the DIN rail, and release the locking tab to
lock the adapter module in place. If necessary, push up on the locking
tab to lock.
5. Connect the adapter wiring. Refer to Wire the ControlNet Adapter on
page 12 .
Panel/Wall Mounting
If mounting the adapter to a panel or wall, refer to publication 1794-5.13 ,
"Panel Mounting Kit, Cat. No. 1794-NM1."
