Analog Output Modules (T7470A)
P D - 7 0 2 5 M a r - 0 6
13
precision load resistors to the analog outputs. Figure 9 shows
the jumper posts to which you should connect the precision
resistors for each analog output channel.
Figure 9. I/O Extender Connections for Analog Output Calibration.
Within each pair of jumper posts, make sure that you connect
the resistors to the jumper posts nearest the front of the I/O
extender. Do not make any connections to the jumper posts
nearest the I/O chassis backplane — these connect to the
actual field wiring attached to the I/O slot terminals on the I/O
chassis.
Calibration Steps
1. Remove the module to be calibrated from the I/O chassis.
Important!
