Page 3: About this publication, Catalog number 2093-prf
Publication 2093-IN003A-MU-P - December 2006
Installation Instructions
Kinetix 2000 Slot Filler Module
Catalog Number 2093-PRF
About This Publication
This publication provides instructions to mount the slot filler module on a Kinetix 2000
power rail.
The slot filler module provides continuity on the contactor enable string in a multi-axis
Kinetix drive system. When installed, it permits energizing of the dc power bus, and prevents
personal exposure to potentially hazardous voltages at an exposed slot on the power rail.
Use this document with the Kinetix 2000 Multi-axis Servo Drive Installation Instructions,
publication 2093-IN001, to install a Kinetix 2000 drive system. For information about
installing or removing equipment and accessories not mentioned here, refer to the
Kinetix 2000 Multi-axis Servo Drive User Manual, publication 2093-IN004.
Topic
Page
About This Publication
3
Mount Slot Fillers
4
