슬롯 필러 설치 – Rockwell Automation 2093-PRF Kinetix 2000 Slot Filler Module Installation Instructions User Manual
Page 18

Publication 2093-IN003A-MU-P - 2006.12
Copyright © 2006 Rockwell Automation, Inc. All rights reserved. Printed in the U.S.A.
슬롯 필러 설치
이 과정은 귀하가 파워레일, 통합 축 모듈 또는 션트 모듈을 설치하였다고 가정한
것입니다 ( 카탈로그 번호 2093-AC05-MP
x
, 2093-AMP
x
, 2093-AM0
x
,
2093-ASP06).
이 과정을 따라서 슬롯 필러 모듈을 Kinetix 2000 파워레일에 설치하십시오 .
1. 어떤 파워레일 슬롯에 슬롯필러 모듈을 설치하여야 하는지 확인하십시오 .
2. 모듈을 해당 파워레일 슬롯에 끼우십시오 .
a. 모듈 잠금 스크류를 파워레일의 해당 슬롯에 정렬하십시오 .
b. 모듈의 위와 아래에 힘을 가하여 모듈을 앞으로 똑바로 미십시오 .
잠금 클립이 파워레일의 아래쪽으로 걸려들어가면 모듈이 완전히 장착된
것이며 , 잠금 스크류 보스는 파워레일의 상부에 접촉하게 됩니다 .
3. 마운팅 스크루를 0.7 Nm (6 lb-in) 로 돌리십시오 .
4. 필요에 따라 이 과정을 반복하여 슬롯 필러를 파워레일의 빈 슬롯에 설치
하십시오 .
Allen-Bradley, Kinetix 및 Rockwell Automation 은 Rockwell Automation, Inc. 의 상표입니다
Rockwell Automation 이외의 상표는 각 상표를 소유한 회사의 재산입니다 .
감전 사고
전기 쇼크로 인한 인명 피해를 방지하기 위해 , 슬롯
필러 모듈을 Kinetix 2000 파워레일의 빈 슬롯에 장착
하십시오 .
파워 레일에 비어있는 슬롯이 있으면 Kinetix 2000
시스템이 비활성화되지만 , 제어용 AC 전원은 파워
레일에 계속 공급됩니다 .
