Remove the protective caps – Rockwell Automation 9904-RPFM ControlNet Modular Repeater Medium-distance Fiber Module Installation Instructio User Manual
Page 8
8 ControlNet Modular Repeater Medium Distance Fiber Module
Publication 9904-IN011A-EN-P - October 2000
Remove the Protective Caps
1. Remove the protective caps from the fiber ports that you are going to use.
2. Save the caps for future use.
Figure 2 Protective Caps
If you plan:
Then:
to place the module in storage
keep the protective caps on the channels to protect
the unit from dust.
not to use channel(s)
keep the protective caps on the channels to protect
the unit from dust.
to connect another module to the right
backplane connector
remove the protective backplane cap and save cap
or future use.
not to connect to the right backplane connector
leave the backplane cap on.
Protective
backplane cap
DIN rail
Protective cap
The left side of the module (not shown here) also
contains a backplane connector
