ControlNet Modular Repeater Medium Distance Fiber Module 15
Publication 9904-IN011A-EN-P - October 2000
Specifications
Communication Rate 5M bits/s
Operation Voltage Class 2 operational power is provided from 9904-RPA at 5 V dc (2)
(2)
Backplane Power Requirements 400 mA maximum
Indicators Channel 1 Status - Green
Channel 2 Status - Green
Environmental Conditions This product must be mounted within a suitable system enclosure to
prevent personal injury resulting from accessibility to live parts. The
interior of this enclosure must be accessible only by the use of a tool.
Operating Temperature 0 to 60 o C (32 to 125 o F)
Storage Temperature -40 to 85 o C (-40 to 185 o F)
Pollution This industrial control equipment is intended to operate in a Pollution
Degree 2 environment, in overvoltage category II applications, (as
defined in IEC publication 664A) at altitudes up to 2000 meters without
derating.
Relative Humidity 5 to 95% non-condensing
Shock Operating
Non-operating
30 g peak acceleration, 11(
±
1)ms pulse width
50 g peak acceleration, 11(
±
1)ms pulse width
Vibration Tested 5 g @ 10-500Hz per IEC 68-2-6
Fiber Type 62.5/125 micron
Fiber Termination TypeST

(plastic or ceramic)
Fiber Operating Wavelength 1300 nm
Optical Power Budget 13.3 dB (1)
LED Light Output 2 <5 mW/mm
(1)
Agency Certification
(when product or package marked)
1 This includes all loss associated with the fiber link, including: splices, fiber attenuation, bulkhead connectors,
and the ST terminations.
2 Power to operate this equipment must be supplied from a source compliant with "Class 2" as defined in the
National Electrical Code ANSI/NFPA 70, or the Canadian Electrical Code - Part 1, C22
Listed Industrial Control Equipment
N223
Certified Process Control Equipment
Certified Class 1, Division 2, Groups A, B, C, D
Marked for all applicable acts
Marked for all applicable directives
