FlexArmor DeviceNet Field Termination Plug 5
Publication 1798-IN004A-EN-P - January 2001
Troubleshooting with the Indicators
The table describes status indicators on the Field Termination Plug.
DeviceNet Field Termination Plug Specifications
Following are specifications for the DeviceNet Field Termination Plug
Indicator
Status
Green
Off
Power ON
Power OFF or reverse polarity
Voltage Rating
28.8V dc maximum
Sensor and Adapter Current
2.5A maximum
Output Current
10A maximum
Sensor/Output Voltage
10-28.8V dc
Sensor/Output Power Connector
0.875 in male
Dimensions (H x D x W)
121 mm x 36.3 mm x 42 mm
4.75 in. x 1.43 in. x 1.65 in.
Environmental Conditions
Operational Temperature
Storage Temperature
Shock Operating
Non-operating
Vibration
-20 to 60°C (-4 to 140°F)
-40 to 85
°
C (-40 to 185
°
F)
30g peak acceleration, 11(±1) ms pulse width
50g peak acceleration, 11(±1) ms pulse width
Tested 5g @ 10-500 Hz per IEC 68-2-6
Conductors
See publication DN-6.7.2
Enclosure
Meets IP67
Agency Certification
(When product is marked)
CUL listed
UL Hazardous Class 1, Division 2, Groups A, B, C, D
certified
CE marked for all applicable directives
marked for all applicable acts
N223
