FlexArmor DeviceNet Field Termination Plug 3
Publication 1798-IN004A-EN-P - January 2001
Install Your DeviceNet Field Termination Plug
To install the module:
•
Mount the DFTP
•
Connect external wiring
These steps are explained in more detail in the following
procedures.
For instructions on how to mount the FlexArmor Baseplate,
refer to publication no. 1798-IN003A-EN-P.
Mount the Field Termination Plug
To mount the Field Termination Plug:
1. Place the DFTP on the left-most slot of the Baseplate.
2. Tighten the 4 screws on the DFTP.
Connect External Wiring
Connect external wiring to the DFTP as shown below.
1. Connect the DeviceNet cable to the DFTP as shown.
IMPORTANT
Torque the screws to 0.5-0.7 Nm. (4.43 - 6.2 inch
pounds).
Connect
Connector Pin
To
BLK Wire
3
-V
BLU Wire
5
CAN* Low
Bare Wire
1
Drain
