4Ć7
4.4.2
Control Block Task Example
The following is an example of a Control Block task that handles an
interrupt from input B19.
Note that the `timeout' parameter in the BASIC statement EVENT is
usually disabled since interrupts from this module do not generally
ocur on a timed basis. The same consideration requires care in using
timeĆbased statements in loops used to read inputs from the module.
The `timeout' parameter is not disabled in the following example
because the interrupt is expected to happen in a specified time
period.
1000
COMMON ISCR%
\!Interrupt Status/Control Register
1010
COMMON LATCH EDGE B19@
\!Latch edge, input B19
1020
COMMON LATCH STATUS B19@
\!Latch status, input B19
1030
COMMON LATCH ENABLE B19@
\!Interrupt enable, input B19
1040
COMMON LATCH RESET B19@
\!Latch reset, input B19
1050
LOCAL B19 CNT%
\!Count of interrupts
2000
!
2001
!
Define the edge transition that will generate an interrupt.
2002
!
2010
LATCH EDGE B19@ = FALSE
\!Off to on
3000
!
3001
!
The following statement connects the name HW EVENT to the
3002
!
Interrupt defined in ISCR%. The event name should be
3003
!
as meaningful as possible. The watchdog timeout has been
3004
!
set to 1800 clock ticks (9.9 sec.). 1 tick equals
3005
!
.0055 seconds. If the time between
3006
!
interrupts exceeds this value, a severe error will be declared
3007
!
and the system will be stopped.
3008
!
3009
!
3010
EVENT NAME=HW EVENT, LATCH STATUS=ISCR%, & TIMEOUT=1800
4000
!
4001
!
The following statement resets the latch status bit
4002
!
4010
LATCH RESET B19@ = FALSE
5000
!
5001
!
The following statement enables interrupts
5002
!
5010
INTRP ENABLE B19@ = TRUE
5200
!
5300
!
complete the remainder of task initilization
5500
!
6000
!
6001
!
The next statement synchronizes the task with the external
6002
!
event via the interrupt. Task execution will be suspended
6003
!
until the interrupt occurs. When the interrupt occurs, if this
6004
!
task is the highest priority task waiting to execute, it will
6005
!
become active. If it is not the highest priority task, it will
6006
!
remain suspended until all higher priority tasks have executed.
6007
!
at which point it will become active.
6008
!
6010
CALL SCAN LOOP( TICKS=1200, EVENT=HW EVENT)
7000
!
7001
!
The next statements determine which bit generated the interrupt
7002
!
by examining the latch status bit. If an interrupt is
7003
!
found, it is reset. The interrupt service routine is
7004
!
then executed.
7005
!
7500
!
