Micro830 16 Point Programmable Controllers 15
Publication 2080-IN003B-EN-P - April 2014
On-state current, min
5 mA @ 79V AC
5.0 mA @ 16.8V DC
1.8 mA @ 10V DC
On-state current, nom
12 mA @ 120V AC
7.66 mA @ 24V
6.15 mA @ 24V
On-state current, max
16 mA @ 132V AC
12.0 mA @ 30V DC
Nominal impedance
12 k
Ω @ 50 Hz
10 k
Ω @ 60 Hz
3 k
Ω
3.74 k
Ω
Inrush current, max
250 mA @ 120V AC
N.A.
Input frequency, max
63 Hz
N.A.
Turn on time/
Turn off time, max
(without filtering)
ON: 1 ms
OFF: 8 ms
ON: 3.2 µs
OFF: 0.6µs
ON: 33 µs…0.1 ms
OFF: 22 µs…0.02 ms
IEC input compatibility
Type 3
AC input filter setting
8 ms for all embedded inputs
In Connected Components Workbench, go to the Embedded I/O
configuration window to reconfigure the filter setting for each
input group.
Output Specifications
Attribute
Relay Output
(2080-LC30-16AWB,
2080-LC30-16QWB
only)
High Speed Output
(2080-LC30-16QVB
only)
(Outputs 0...1)
Standard Output
(2080-LC30-16QV
B only)
(Outputs 2....5)
Number of outputs
6
2
4
Output voltage, min
5V DC, 5V AC
10.8V DC
10V DC
Output voltage, max
125V DC, 265V AC
26.4V DC
26.4V DC
Load current, min
10 mA
10 mA
10 mA
Load current, max
2.0 A
100 mA (high-speed
operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
Surge current, per point
See
4.0 A for 10 ms every 1 s @ 30 °C; every 2 s
@ 65 °C
(1)
Input Specifications
Attribute
120V AC Input
(2080-LC30-16AWB
only)
High Speed DC Input
(2080-LC30-16QVB
and
2080-LC30-16QWB
only)
(Inputs 0...3)
Standard DC Input
(2080-LC30-16QVB
and
2080-LC30-16QWB
only)
(Inputs 4...9)
