8 Continuous-flex Feedback Cables with SpeedTec DIN Connector
Publication 2090-IN027B-EN-P - January 2011
2090-CFBM7DF-CEAFxx Cable
This cable is available in several cable lengths with flying leads for connection to a drive. Refer to
the Kinetix Motion Control Selection Guide, publication
, for this information
and additional specifications.
1
2
3
4
5
10
14
6
7
11
22 AWG Black
22 AWG White/Black
22 AWG Red
22 AWG White/Red
22 AWG Green
22 AWG White/Green
22 AWG Gray
22 AWG White/Gray
22 AWG Orange
22 AWG White/Orange
1
2
3
4
5
6
9
10
11
13
14
12
SIN+/AM+
SIN-/AM-
COS+/BM+
COS-/BM-
DATA+/IM+/R1
DATA-/IM-/R2
EPWR 5V
ECOM
EPWR 9V
TS+
TS-
ECOM
SIN+/AM+
SIN-/AM-
COS+/BM+
COS-/BM-
DATA+/IM+
DATA-/IM-
EPWR 5V
ECOM
EPWR 9V
TS+
1
2
3
4
5
16
15
14
13
12
11
10
9
8
7
6
17
Twisted Wire Pair
Connector Backshell Shielded 360°
Wire Connection
Shield
Connect Cable Shield to Ground
To
Motor
To
Drive
