Continuous-flex Feedback Cables with SpeedTec DIN Connector 11

Publication 2090-IN027B-EN-P - January 2011

Specifications

These specifications provide information that is useful when installing a cable. Additional
specifications for each cable are available in the Kinetix Motion Control Selection Guide

,

publication

GMC-SG001

.

2090-CFBM7DF-CDAFxx and 2090-CFBM7E7-CDAFxx Cables

2090-CFBM7DD-CEAFxx, 2090-CFBM7DF-CEAFxx, and
2090-CFBM7E7-CEAFxx
Cables

Attribute

2090-CFBM7xx-CDAFxx

Diameter 12.0 mm

(0.5 in.)

Bend radius

(1)

(1)

Apply the bend radius multiplier for operational (12 x dia.) and static (10 x dia.) bend radius to cables with a different
diameter. Refer to the diagram to locate the areas for flex (operational) and static (installation) bend areas.

Flex area

140 mm (5.5 in.)

Installation areas

(2)

(2)

The installation areas are approximately 300 mm (12 in.) in length at both ends of the cable. Secure this area with a rigid
mount that prevents the cable from flexing where it connects to other components.

120 mm (5.0 in.)

Attribute

2090-CFBM7xx-CEAFxx

Diameter 10.0 mm

(0.395 in.)

Bend radius

(1)

(1)

Apply the bend radius multiplier for operational (12 x dia.) and static (10 x dia.) bend radius to cables with a different
diameter. Refer to the diagram to locate the areas for flex (operational) and static (installation) bend areas.

Flex area

120 mm (5.0 in.)

Installation areas

(2)

(2)

The installation areas are approximately 300 mm (12 in.) in length at both ends of the cable. Secure this area with a rigid
mount that prevents the cable from flexing where it connects to other components.

100 mm (4.0 in.)
