Single Motor Cables with Circular DIN Connector Type 740 3
Rockwell Automation Publication 2090-IN049A-EN-P - October 2013
Cable Pinouts and Schematics
This diagrams provides wire colors and pinouts for single motor cables with brake conductors.
2090-CSBM1DF-10AF
xx Cable (with brake)
Specifications
Additional specifications for each cable are available in the Kinetix Motion Accessories
Specifications Technical Data, publication
GMC-TD004 .
Attribute 2090-CSBM1DF-10AF
xx
Conductor size (gauge):
DC bus
Digital servo link (data)
(1)
Brake
(1) Controlled impedance data pair.
5.4 mm
2
(10 AWG)
0.4 mm 2 (22 AWG)
0.4 mm 2 (22 AWG)
Diameter 19 mm (0.75 in.)
Continuous-flex zone radius, max 190 mm (7.5 in.)
U
V
W
GND
BRK+
BRK-
+
U
V
W
1
2
L
H
U V
2 +
H
L
1
N W
The braided shields
are grounded to the
motor connector.
Shield Connection
To
Drive
Twisted Wire Pair
Braided Shield
To
Motor
Brown
Black
Blue
Green/Yellow
Black
White
Blue
White/Blue
Braided Shield
