Rockwell Automation 2094-PRF Kinetix 6000 Slot-filler Module Install User Manual
Page 3
Kinetix 6000 Slot-filler Module 3
Publication 2094-IN006B-EN-P — June 2008
3. Hang the mounting bracket from the slot on the power rail.
4. Pivot module downward and align the guide pins on the power rail with the
guide pin holes in the back of the module.
Slots for additional axis modules,
shunt module, or slot-filler modules.
Power Rail Slot
Mounting Bracket
Power Rail
IAM, AM, Shunt, or
Slot-filler Module
(IAM module is shown)
Guide Pin
Holes
Power rail (side view)
in upright vertical position.
IAM, AM, Shunt, or
Slot-filler Module, Side View
(IAM module is shown)
Guide Pins
Pivot module downward
and align with guide pins.
IAM, AM, Shunt, or
Slot-filler Module, Rear View
(IAM module is shown)
