Remote Keyswitch and RS-232 Assembly

Installation Data

7. Set the Mode Select Keyswitch on the back of the terminal to Run

Mode, otherwise the Remote Keyswitch and RS-232 Port will not be
able to operate (see Figure 4).

8. Hand-tighten the cap securely to maintain a NEMA 4X seal when the

Remote Keyswitch and RS-232 Port Assembly is not in use.

Figure 5
Cable Diagram

20217

25-Pin D-Shell
Connector

1
2
3
4
5
6
7
8
20
21
24

Shield
RxD
TxD
CTS
RTS
DTR
COM
DCD
DSR
EXMODE
AGND

Remote
25-Pin D-Shell
Connector

1
2
3
4
5
6
7
8
20

Shield
RxD
TxD
CTS
RTS
DTR
COM
DCD
DSR

Remote Keyswitch
