Page 3
Antiglare Overlay 3
Publication 2711-IN054A-EN-P - March 2007
Precautions
Follow these precautions when installing the overlays on a terminal screen.
• Make sure your hands are clean, free of grease, and dry.
• Handle the overlay by the edges to prevent marking it with fingerprints or
lint. If you get lint or marks on the overlay, remove them before proceeding.
• Do not touch the adhesive ring.
About the Antiglare Overlay
The protective antiglare overlay covers the entire face of the bezel including the
keypad. The antiglare overlay has a protective layer which can be removed by
pulling back on the tab. Do not remove the protective layer until you are ready to
install the overlay.
Install the Overlay
Remove all grease, fingerprints, streaks and lint from the terminal screen by using a
clean, lint-free cloth, and Windex or a similar glass cleaner. Any marks will be
trapped underneath the overlay. Grease also affects the adhesion of the overlay.
Follow these steps to install the antiglare overlay.
1. Grasp the tab and partially peel back the protective layer covering the
overlay from one of the short sides.
Adhesive Ring
Tab
Protective Layer
