Removeable Media 4
4. From the bottom of the chassis (under the accessory drive),
remove the 4 screws that secure the accessory drive/ bracket
assembly.
Accessory Drive /
Bracket Assembly
Mounting Screws (4)
6180 Computer
(Bottom View)
5. The sequence of the following steps depends on whether the drive
is mounted to the rear or front:
•
If mounted for front access, do step 6 then step 7.
•
If mounted for rear access, do step 7 then step 6.
6. Disconnect the ribbon cable connector and power cable connector
from the drive.
Power Connector
Ribbon Cable
Floppy or CD ROM Drive
Mounting Bracket
Not Illustrated
7. Remove the accessory drive / bracket assembly through the back
of the chassis.
