Page 4

4 Optical Disc Drive (ODD)
Publication 6177R-IN004B-EN-P - November 2009
About the Optical Disc Drive (ODD)
The ODD supports reading and writing data to compatible CD and DVD media. Data may
be written to CD media by using either the Windows XP CD writing wizard or the DVD
burning software provided with this product. The burning software must be used when
writing data to DVD media.
Before You Begin
Review the specifications of a new component before installing it to make sure it is
compatible with the computer. Record the model and serial number, and any other pertinent
information of new components for future reference.
Required Tools
These tools are required:
•
#2 Phillips screwdriver
•
Antistatic wrist band (ships with product)
•
Small wire cutter
ATTENTION
To avoid voiding your product warranty, use only Rockwell Automation
Allen-Bradley approved replacement parts and accessories.
